627B Cobalt Short Series Slot Drills Flatted Shank

In stock

SKU

627B

Parallel shank with flat*                                  M42 HSS+8% Cobalt                                     DIN327B Typ N
Teeth end cutting to centre                             30° Right hand spiral                                     Right hand cutting
Shank tolerance h6

*Shanks according to DIN1835 Type B, with flat for locking, will fit standard sidelock holders, and also plain collets.

Grouped product items
Product Name	Diameter	Shank Diam	Cutting Length	Total Length
627B 1.00mm Co. DIN327B Slot Drill £17.22 - 45 in stock	1.00mm	6	4	48
627B 1.50mm Co. DIN327B Slot Drill £17.22 - 12 in stock	1.50mm	6	4	48
627B 2.50mm Co. DIN327B Slot Drill £20.70 - 8 in stock	2.50mm	6	5	49
627B 3.00mm Co. DIN327B Slot Drill £17.22 - 93 in stock	3.00mm	6	5	49
627B 3.50mm Co. DIN327B Slot Drill £20.70 - 10 in stock	3.50mm	6	6	50
627B 4.00mm Co. DIN327B Slot Drill £17.22 - 201 in stock	4.00mm	6	7	51
627B 4.50mm Co. DIN327B Slot Drill £20.70 - 15 in stock	4.50mm	6	7	51
627B 5.00mm Co. DIN327B Slot Drill £17.22 - 64 in stock	5.00mm	6	8	52
627B 5.50mm Co. DIN327B Slot Drill £20.70 - 18 in stock	5.50mm	6	8	52
627B 6.00mm Co. DIN327B Slot Drill £17.22 - 56 in stock	6.00mm	6	8	52
627B 6.50mm Co. DIN327B Slot Drill £27.65 - 20 in stock	6.50mm	10	10	60
627B 7.00mm Co. DIN327B Slot Drill £23.41 - 2 in stock	7.00mm	10	10	60
627B 7.50mm Co. DIN327B Slot Drill £27.65 - 1 in stock	7.50mm	10	10	60
627B 8.00mm Co. DIN327B Slot Drill £23.21 - 48 in stock	8.00mm	10	11	61
627B 8.50mm Co. DIN327B Slot Drill £31.34 - 22 in stock	8.50mm	10	11	61
627B 9.00mm Co. DIN327B Slot Drill £27.47 - 10 in stock	9.00mm	10	11	61
627B 9.50mm Co. DIN327B Slot Drill £28.62 - 49 in stock	9.50mm	10	11	61
627B 10.00mm Co. DIN327B Slot Drill £23.21 - 23 in stock	10.00mm	10	13	63
627B 11.00mm Co. DIN327B Slot Drill £32.88 - 23 in stock	11.00mm	12	13	70
627B 12.00mm Co. DIN327B Slot Drill £27.47 - 53 in stock	12.00mm	12	16	73
627B 13.00mm Co. DIN327B Slot Drill £48.36 - 7 in stock	13.00mm	12	16	73
627B 14.00mm Co. DIN327B Slot Drill £35.59 - 6 in stock	14.00mm	12	16	73
627B 15.00mm Co. DIN327B Slot Drill £49.32 - 6 in stock	15.00mm	12	16	73
627B 16.00mm Co. DIN327B Slot Drill £36.75 - 17 in stock	16.00mm	16	19	79
627B 17.50mm Co. DIN327B Slot Drill £51.26 - 3 in stock	17.50mm	16	19	79
627B 18.00mm Co. DIN327B Slot Drill £51.26 - 1 in stock	18.00mm	16	19	79
627B 19.00mm Co. DIN327B Slot Drill £51.26 - 7 in stock	19.00mm	16	19	79
627B 20.00mm Co. DIN327B Slot Drill £49.32 - 2 in stock	20.00mm	20	22	88
627B 22.00mm Co. DIN327B Slot Drill £100.58 - 33 in stock	22.00mm	20	22	88
627B 24.00mm Co. DIN327B Slot Drill £125.73 - 6 in stock	24.00mm	25	25	102
627B 25.00mm Co. DIN327B Slot Drill £96.71 - 4 in stock	25.00mm	25	25	102
627B 28.00mm Co. DIN327B Slot Drill £96.71 - 1 in stock	28.00mm	25	26	102
627B 30.00mm Co. DIN327B Slot Drill £133.46 - 12 in stock	30.00mm	25	25	102
627B 36.00mm Co. DIN327B Slot Drill £133.46 - 1 in stock	36.00mm	32	31	112

Details

Intermediate sizes may be provided to special order, the quantity ordered determining the unit price.
