626F Cobalt Long Series Ball Nose Flatted Shank

In stock

SKU

626F

Parallel shank with flat*                                   M42 HSS+8% Cobalt                                     DIN327B Long Series**+RADIUS
Teeth end cutting to centre                              30° Right hand spiral                                      Right hand cutting
Shank tolerance h6                                          2 Flutes

*Shanks according to DIN1835 Type B, with flat for locking, will fit standard sidelock holders, and also plain collets
**Overall length is the same as DIN844 standard length which applies to mulktiflute end mills

Grouped product items
Product Name	Diameter	Radius	Shank Diam	Cutting Length	Overall Length
626F 3.00mm L/S B/N Flatted Shank Slot Drill £31.91 - 73 in stock	3.00mm	R=1.5	6	8	56
626F 4.00mm L/S B/N Flatted Shank Slot Drill £31.91 - 100 in stock	4.00mm	R=2	6	11	63
626F 5.00mm L/S B/N Flatted Shank Slot Drill £31.91 - 72 in stock	5.00mm	R=2.5	6	13	68
626F 6.00mm L/S B/N Flatted Shank Slot Drill £31.91 - 81 in stock	6.00mm	R=3	6	13	68
626F 7.00mm L/S B/N Flatted Shank Slot Drill £43.53 - 29 in stock	7.00mm	R=3.5	10	16	80
626F 8.00mm L/S B/N Flatted Shank Slot Drill £43.53 - 126 in stock	8.00mm	R=4	10	19	88
626F 9.00mm L/S B/N Flatted Shank Slot Drill £56.09 - 25 in stock	9.00mm	R=4.5	10	19	88
626F 10.00mm L/S B/N Flatted Shank Slot Drill £56.09 - 150 in stock	10.00mm	R=5	10	22	95
626F 11.00mm L/S B/N Flatted Shank Slot Drill £61.90 - 67 in stock	11.00mm	R=5.5	12	22	102
626F 12.00mm L/S B/N Flatted Shank Slot Drill £61.90 - 111 in stock	12.00mm	R=6	12	26	110
626F 13.00mm L/S B/N Flatted Shank Slot Drill £92.85 - 36 in stock	13.00mm	R=6.5	12	26	110
626F 14.00mm L/S B/N Flatted Shank Slot Drill £92.85 - 31 in stock	14.00mm	R=7	12	26	110
626F 15.00mm L/S B/N Flatted Shank Slot Drill £106.38 - 35 in stock	15.00mm	R=7.5	16	26	110
626F 16.00mm L/S B/N Flatted Shank Slot Drill £100.58 - 120 in stock	16.00mm	R=8	16	32	123
626F 17.00mm L/S B/N Flatted Shank Slot Drill £112.19 - 29 in stock	17.00mm	-	-	-	-
626F 18.00mm L/S B/N Flatted Shank Slot Drill £112.19 - 25 in stock	18.00mm	R=9	16	32	123
626F 19.00mm L/S B/N Flatted Shank Slot Drill £116.06 - 22 in stock	19.00mm	-	-	-	-
626F 20.00mm L/S B/N Flatted Shank Slot Drill £116.06 - 31 in stock	20.00mm	R=10	16	38	141
626F 22.00mm L/S B/N Flatted Shank Slot Drill £173.35 - 4 in stock	22.00mm	R=11	20	38	141
626F 24.00mm L/S B/N Flatted Shank Slot Drill £212.77 - 27 in stock	24.00mm	R=12	25	45	166
626F 25.00mm L/S B/N Flatted Shank Slot Drill £212.77 - 47 in stock	25.00mm	R=12.5	25	45	166
626F 30.00mm L/S B/N Flatted Shank Slot Drill £348.17 - 9 in stock	30.00mm	R=15	25	45	166

Details

Intermediate sizes may be provided to special order, the quantity ordered determining the unit price.
