623L 3 Flute Mills Medium Series Threaded Shank

In stock
SKU
623L
Parallel shank with thread*                                   M42 HSS+8% Cobalt                                  BS122 Part 4
Teeth end cutting to centre 30° Right hand spiral Right hand cutting
Shank tolerance h8 20TPI Whit Form Thread

*Shanks are designed to fit plain collets as thread crests are below shank diameter, as well as Clarkson and
similar threaded collets.
A metric standard, DIN1835 Type D, has been used to describe the shanks.
Grouped product items
Product Name Diameter Shank Diam Cutting Length Total Length Qty
623L 2.50mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
2.50mm 6 8 52
Out of stock
623L 3.00mm 3FL Cutter Combi Shank
£20.32
-
1 in stock
3.00mm 6 8 52
623L 4.00mm 3FL Cutter Combi Shank
£20.32
-
19 in stock
4.00mm 6 11 55
623L 5.00mm 3FL Cutter Combi Shank
£20.32
-
7 in stock
5.00mm 6 13 57
623L 6.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
6.00mm 6 13 57
Out of stock
623L 7.00mm 3FL Cutter Combi Shank
£29.02
-
5 in stock
7.00mm 10 16 66
623L 8.00mm 3FL Cutter Combi Shank
£23.21
-
2 in stock
8.00mm 10 19 69
623L 9.00mm 3FL Cutter Combi Shank
£36.75
-
9 in stock
9.00mm 10 19 69
623L 10.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
10.00mm 10 22 72
Out of stock
623L 11.00mm 3FL Cutter Combi Shank
£39.66
-
5 in stock
11.00mm 12 22 79
623L 12.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
12.00mm 12 26 83
Out of stock
623L 14.00mm 3FL Cutter Combi Shank
£38.69
-
1 in stock
14.00mm 12 26 83
623L 16.00mm 3FL Cutter Combi Shank
£46.43
-
3 in stock
16.00mm 16 32 92
623L 18.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
18.00mm 16 32 92
Out of stock
623L 20.00mm 3FL Cutter Combi Shank
£65.77
-
25 in stock
20.00mm 20 38 104
623L 22.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
- - - -
Out of stock
623L 25.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
25.00mm 25 45 121
Out of stock
623L 26.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
- - - -
Out of stock
623L 28.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
- - - -
Out of stock
623L 30.00mm 3FL Cutter Combi Shank - POA
£160.55
-
Out of stock
30.00mm 25 46 104.5
Out of stock
623L 32.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
32.00mm 32 51 112.5
Out of stock
623L 35.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
- - - -
Out of stock
623L 38.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
- - - -
Out of stock
623L 40.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
40.00mm 32 55.5 117.5
Out of stock
623L 45.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
- - - -
Out of stock
623L 50.00mm 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
50.00mm 32 65 127
Out of stock
623L 3/8 3FL Cutter Combi Shank
£44.50
-
3 in stock
3/8 3/8 1,3/8 3,1/8
623L 1/2 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
1/2 1/2 2 3,13/16
Out of stock
623L 1" 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
1" 1 3,15/16 6,1/2
Out of stock
623L 1.1/8 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
- - - -
Out of stock
623L 1.1/2 3FL Cutter Combi Shank
£386.86
-
3 in stock
1,1/2 1,1/4 3,15/16 6,5/16
623L 1.5/8 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
- - - -
Out of stock
623L 2" 3FL Cutter Combi Shank - POA
£0.00
-
Out of stock
2" 1,1/4 4 6,11/16
Out of stock
Intermediate sizes may be provided to special order, the quantity ordered determining the unit price.
For 623L cutters with TiCN coating, please see No. 623X
NOTE RELATING TO 623 series mills— 3-Flute cutters stand between 2-flute slot drills and multiflute end mills. Continental
suppliers generally default to the shorter DIN327 (Slot Drill) lengths, whereas British makers have usually followed the longer End Mill
data for threaded shank 3-Flute. This leads to some terminological confusion. Large stocks exist of cutters made to DIN327 long series,
but with combination (Flatted+Threaded) shanks. They are of very similar length to DIN623L above, and may be offered in place of
623L where the definitive item is not available. The combi shank tools are available only while stocks last, and then become special.
