205B 4 Flute Taper Shank Core Drills

In stock
SKU
205B
Morse Taper Shank ISO Length                        M2 High Speed Steel                        BS328/1 DIN343RN
30° relieved chamfer nose h8 diameter tolerance Right hand cutting
Normally supplied in steam temper (‘blue’) finish.

For opening out drilled, cored, or punched holes. Core drills are very rigid and robust tools for producing
accurately sizes, very round, well aligned holes, to a higher standard of surface finish than is attained with a
two-fluted drill. Core drills will not drill from the solid.

It is possible to provide any of the sizes listed as standard 3-flute core drills on the previous pages, in 4-flute design.
However, the sizes below are normally held in stock in 4-flute. They are concentrated in the larger diameters.
Grouped product items
Product Name Diameter Flute Length Overall Length Morse Taper Number Qty
205B 12.83mm 4FL MTS Core Drill
£63.38
-
5 in stock
12.83mm 101 182 1
205B 13.00mm 4FL MTS Core Drill
£49.94
-
6 in stock
13.00mm 101 182 1
205B 14.00mm 4FL MTS Core Drill
£55.72
-
65 in stock
14.00mm 108 189 1
205B 15.00mm 4FL MTS Core Drill
£61.47
-
19 in stock
15.00mm 114 212 2
205B 16.00mm 4FL MTS Core Drill
£67.23
-
11 in stock
16.00mm 120 218 2
205B 17.00mm 4FL MTS Core Drill
£74.92
-
1 in stock
17.00mm 125 223 2
205B 17.75mm 4FL MTS Core Drill
£124.85
-
37 in stock
17.75mm 130 228 2
205B 18.00mm 4FL MTS Core Drill
£80.67
-
32 in stock
18.00mm 130 228 2
205B 18.00mm 4FL MTS Core Drill (NP)
£80.69
-
2 in stock
18.00mm 130 228 2
205B 19.00mm 4FL MTS Core Drill
£90.28
-
Out of stock
19.00mm 135 233 2
Out of stock
205B 19.20mm 4FL MTS Core Drill
£155.60
-
Out of stock
19.20mm 140 238 2
Out of stock
205B 20.00mm 4FL MTS Core Drill
£97.97
-
6 in stock
20.00mm 140 238 2
205B 21.00mm 4FL MTS Core Drill
£107.57
-
1 in stock
21.00mm 145 243 2
205B 22.00mm 4FL MTS Core Drill
£117.17
-
3 in stock
22.00mm 150 248 2
205B 22.00mm 4FL MTS Core Drill (NP)
£117.17
-
1 in stock
22.00mm 150 248 2
205B 23.00mm 4FL MTS Core Drill
£128.70
-
9 in stock
23.00mm 155 253 2
205B 24.00mm 4FL MTS Core Drill
£138.30
-
3 in stock
24.00mm 160 281 3
205B 25.00mm 4FL MTS Core Drill
£149.83
-
9 in stock
25.00mm 160 281 3
205B 25.50mm 4FL MTS Core Drill
£243.96
-
7 in stock
25.50mm 165 286 3
205B 26.00mm 4FL MTS Core Drill
£240.11
-
1 in stock
26.00mm 165 286 3
205B 27.00mm 4FL MTS Core Drill
£261.25
-
7 in stock
27.00mm 170 291 3
205B 28.00mm 4FL MTS Core Drill
£282.38
-
Out of stock
28.00mm 170 291 3
Out of stock
205B 29.00mm 4FL MTS Core Drill
£303.51
-
Out of stock
29.00mm 175 296 3
Out of stock
205B 30.00mm 4FL MTS Core Drill
£217.06
-
Out of stock
30.00mm 175 296 3
Out of stock
205B 31.00mm 4FL MTS Core Drill
£349.60
-
4 in stock
31.00mm 180 301 3
205B 32.00mm 4FL MTS Core Drill (NP)
£374.58
-
24 in stock
32.00mm 185 334 4
205B 33.00mm 4FL MTS Core Drill
£401.47
-
1 in stock
33.00mm 185 334 4
205B 34.00mm 4FL MTS Core Drill
£430.30
-
Out of stock
34.00mm 190 339 4
Out of stock
205B 35.00mm 4FL MTS Core Drill
£305.43
-
Out of stock
35.00mm 190 339 4
Out of stock
205B 36.00mm 4FL MTS Core Drill
£487.91
-
6 in stock
36.00mm 195 344 4
205B 37.00mm 4FL MTS Core Drill
£522.49
-
2 in stock
37.00mm 195 344 4
205B 38.00mm 4FL MTS Core Drill
£537.87
-
Out of stock
38.00mm 200 349 4
Out of stock
205B 39.00mm 4FL MTS Core Drill
£576.29
-
Out of stock
39.00mm 200 349 4
Out of stock
205B 40.00mm 4FL MTS Core Drill
£414.92
-
2 in stock
40.00mm 200 349 4
205B 42.00mm 4FL MTS Core Drill
£612.78
-
Out of stock
42.00mm 205 354 4
Out of stock
205B 43.00mm 4FL MTS Core Drill
£647.35
-
1 in stock
43.00mm 210 359 4
205B 45.00mm 4FL MTS Core Drill
£553.22
-
6 in stock
45.00mm 210 359 4
205B 46.00mm 4FL MTS Core Drill
£875.94
-
Out of stock
46.00mm 215 364 4
Out of stock
205B 47.00mm 4FL MTS Core Drill
£923.97
-
1 in stock
47.00mm 215 364 4
205B 50.00mm 4FL MTS Core Drill
£720.35
-
Out of stock
50.00mm 220 369 4
Out of stock
205B 53.00mm 4FL MTS Core Drill
£1,056.51
-
3 in stock
53.00mm 225 412 5
205B 55.00mm 4FL MTS Core Drill
£1,248.61
-
1 in stock
55.00mm 230 417 5
205B 60.00mm 4FL MTS Core Drill
£1,440.69
-
Out of stock
60.00mm 235 422 5
Out of stock
205B 61.00mm 4FL MTS Core Drill
£1,498.53
-
1 in stock
61.00mm 240 427 5
205B 62.00mm 4FL MTS Core Drill
£1,517.74
-
3 in stock
62.00mm 240 427 5
205B 63.00mm 4FL MTS Core Drill
£1,728.85
-
2 in stock
63.00mm 240 427 5
205B 21/64 4FL MTS Core Drill
£49.95
-
1 in stock
21/64 2,15/16 6,1/8 1
205B 29/64 4FL MTS Core Drill (NP)
£69.16
-
1 in stock
29/64 3,11/16 6,7/8 1
205B 1/2 4FL MTS Core Drill (NP)
£48.03
-
2 in stock
1/2 3,31/32 7,5/32 1
205B 33/64 4FL MTS Core Drill
£74.92
-
8 in stock
33/64 3,31/32 7,5/32 1
205B 33/64 4FL MTS Core Drill (NP)
£74.92
-
1 in stock
33/64 3,31/32 7,5/32 1
205B 17/32 4FL MTS Core Drill (NP)
£51.87
-
46 in stock
17/32 4,1/4 7,7/16 1
205B 9/16 4FL MTS Core Drill
£55.70
-
6 in stock
9/16 4,1/2 8,3/8 2
205B 9/16 4FL MTS Core Drill (NP)
£55.70
-
14 in stock
9/16 4,1/2 8,3/8 2
205B 37/64 4FL MTS Core Drill
£88.36
-
9 in stock
37/64 4,1/2 8,3/8 2
205B 5/8 4FL MTS Core Drill
£67.24
-
4 in stock
5/8 4,3/4 8,5/8 2
205B 41/64 4FL MTS Core Drill
£105.66
-
12 in stock
41/64 4,7/8 8,3/4 2
205B 21/32 4FL MTS Core Drill
£71.07
-
11 in stock
21/32 4,7/8 8,3/4 2
205B 11/16 4FL MTS Core Drill
£76.84
-
3 in stock
11/16 5,1/8 9 2
205B 45/64 4FL MTS Core Drill
£124.86
-
7 in stock
45/64 5,1/8 9 2
205B 45/64 4FL MTS Core Drill (NP)
£124.85
-
10 in stock
45/64 5,1/8 9 2
205B 23/32 4FL MTS Core Drill
£84.54
-
9 in stock
23/32 5,1/4 9,1/8 2
205B 47/64 4FL MTS Core Drill
£130.63
-
57 in stock
47/64 5,1/4 9,1/8 2
205B 3/4 4FL MTS Core Drill
£90.28
-
1 in stock
3/4 5,1/2 9,3/8 2
205B 3/4 4FL MTS Core Drill (NP)
£90.28
-
4 in stock
3/4 5,1/2 9,3/8 2
205B 13/16 4FL MTS Core Drill
£94.13
-
Out of stock
13/16 5,3/4 9,5/8 2
Out of stock
205B 27/32 4FL MTS Core Drill
£111.41
-
6 in stock
27/32 5,7/8 9,3/4 2
205B 55/64 4FL MTS Core Drill
£182.49
-
1 in stock
55/64 5,7/8 9,3/4 2
205B 29/32 4FL MTS Core Drill
£128.71
-
Out of stock
29/32 6,1/8 10 2
Out of stock
205B 59/64 4FL MTS Core Drill
£197.86
-
32 in stock
59/64 6,1/8 10,7/8 3
205B 15/16 4FL MTS Core Drill
£136.39
-
17 in stock
15/16 6,1/4 11 3
205B 61/64 4FL MTS Core Drill
£211.30
-
10 in stock
61/64 6,1/4 11 3
205B 31/32 4FL MTS Core Drill
£146.00
-
22 in stock
31/32 6,1/4 11 3
205B 63/64 4FL MTS Core Drill
£220.90
-
25 in stock
63/64 6,1/2 11,1/4 3
205B 1" 4FL MTS Core Drill
£153.67
-
Out of stock
1 6,1/2 11,1/4 3
Out of stock
205B 1" 4FL MTS Core Drill (NP)
£153.67
-
4 in stock
1 6,1/2 11,1/4 3
205B 1.1/32 4FL MTS Core Drill
£245.88
-
8 in stock
1,1/32 6,1/2 11,1/4 3
205B 1.1/16 4FL MTS Core Drill
£261.25
-
1 in stock
1,1/16 6,5/8 11,3/8 3
205B 1.3/32 4FL MTS Core Drill
£278.53
-
8 in stock
1,3/32 6,5/8 11,3/8 3
205B 1.1/8 4FL MTS Core Drill
£195.93
-
9 in stock
1,1/8 6,7/8 11,5/8 3
205B 1.3/16 4FL MTS Core Drill
£328.48
-
2 in stock
1,3/16 7,1/8 11,7/8 3
205B 1.1/4 4FL MTS Core Drill
£245.88
-
1 in stock
1,1/4 7,1/4 12 3
205B 1.5/16 4FL MTS Core Drill (NP)
£409.17
-
7 in stock
1,5/16 7,1/4 13,1/8 4
205B 1.3/8 4FL MTS Core Drill
£303.50
-
1 in stock
1,3/8 7,1/2 13,3/8 4
205B 1.1/2 4FL MTS Core Drill
£372.67
-
5 in stock
1,1/2 7,7/8 13,3/4 4
205B 1.9/16 4FL MTS Core Drill
£612.78
-
2 in stock
1,9/16 7,7/8 13,3/4 4
205B 1.5/8 4FL MTS Core Drill
£451.45
-
2 in stock
1,5/8 8,1/8 14 4
205B 1.11/16 4FL MTS Core Drill
£737.64
-
1 in stock
1,11/16 8,1/4 14,1/8 4
205B 1.7/8 4FL MTS Core Drill
£956.63
-
1 in stock
1,7/8 8,5/8 14,1/2 4
205B 1.15/16 4FL MTS Core Drill
£1,039.23
-
1 in stock
1,15/16 8,5/8 14,1/2 4
205B 2" 4FL MTS Core Drill
£752.99
-
6 in stock
2 8,7/8 14,3/4 4
205B 2.5/64 4FL MTS Core Drill
£1,152.56
-
6 in stock
2,5/64 8,7/8 16,1/4 5
205B 2.1/8 4FL MTS Core Drill
£1,085.33
-
2 in stock
2,1/8 9 16,3/8 5
205B 2.1/2 4FL MTS Core Drill
£1,421.49
-
2 in stock
2,1/2 9,5/8 17 5
205B 3" 4FL MTS Core Drill
£2,305.13
-
3 in stock
3 10,1/4 17,5/8 5
