195A 3 Flute Straight Shank Core Drills
In stock
SKU
195A
Parallel shank jobber length M2 High Speed Steel To BS328[and similar to DIN344RN*]
120° included lip angle h8 diameter tolerance Right hand cutting
Heavy web construction For opening out existing drilled, cored or punched holes
Core drills will not drill from solid, but used correctly will produce rounder, straighter, and more accurate holes
than are made by a normal 2-fluted drill. They are a much underestimated product, and are the tool of choice
when opening out an existing hole. Surface finish is also definitely improved, and in some circumstances the
employment of a reamer can be rendered unnecessary.
* note re- DIN344 drills vs. TRUBOR No.195A
The German standard DIN844 is based on the lengths used in DIN340 (i.e. long series / taper length),
whereas Trubor No. 195A are made to normal jobber length.. DIN344 drills are also usually equipped
with a tang on the shank. In case DIN344 is actually demanded, tools must be made to special order,
the quantity ordered determining the unit price.
For larger diameters, and a greater range of sizes, please see Taper Shank Core Drills (205A and 205B)
Core drilling should be executed at approximately the same drilling speeds as would be employed using a 2-fluted drill of the same
diameter. Feeds used should be intermediate between those recommended for a drill and for a reamer in similar circumstances.
Core drills will routinely open out existing holes or 75% of the core drill diameter, or greater.
