150Y Tin Supercobalt Jobber

In stock
SKU
150Y
Parallel shank ISO length                                 M42 8% Cobalt High Speed Steel                BS328/1 DIN338RN
Aerospace quality 135° split point, h8 diameter tolerance Right hand cutting
150M Supercobalt drills given a PVD coating of Titanium Nitride (yellow-gold finish)*

For dimensions please see No. 150A


*The coating gives the drill a superhard surface which is claimed to give greater durability and capability to the tool.

The surface is low-friction and may improve lubrication. Although TiN coating has advantages in some particular
applications, our engineers RECOMMEND that these drills are only specified where the coating has been shown to
be advantageous. Note that the coating at the cutting tip, where it operates, will wear fairly quickly and progressively
lose much of its function.

The sizes below are generally in stock. Sizes not listed may be coated to order, the unit price depending upon the quantity ordered.
Grouped product items
Product Name Decimal Equiv Diameter Flute Length Overall Length Qty
150Y 1.50mm Tin Co. Jobber Drills
£6.91
.0591 1.50mm 18 40
150Y 1.60mm Tin Co. Jobber Drills
£7.30
.0630 1.60mm 20 43
150Y 1.80mm Tin Co. Jobber Drills
£7.30
.0709 1.80mm 22 46
150Y 1.85mm Tin Co. Jobber Drills
£7.69
.0728 1.85mm 22 46
150Y 1.90mm Tin Co. Jobber Drills
£7.30
.0748 1.90mm 22 46
150Y 2.00mm Tin Co. Jobber Drills
£6.91
.0787 2.00mm 24 49
150Y 2.10mm Tin Co. Jobber Drills
£6.91
.0827 2.10mm 24 49
150Y 2.20mm Tin Co. Jobber Drills
£6.91
.0866 2.20mm 27 53
150Y 2.30mm Tin Co. Jobber Drills
£6.91
.0906 2.30mm 27 53
150Y 2.40mm Tin Co. Jobber Drills
£7.12
.0945 2.40mm 30 57
150Y 2.50mm Tin Co. Jobber Drills
£7.12
.0984 2.50mm 30 57
150Y 2.60mm Tin Co. Jobber Drills
£7.12
.1024 2.60mm 30 57
150Y 2.70mm Tin Co. Jobber Drills
£7.12
.1063 2.70mm 33 61
150Y 2.80mm Tin Co. Jobber Drills
£7.30
.1102 2.80mm 33 61
150Y 2.90mm Tin Co. Jobber Drills
£7.50
.1142 2.90mm 33 61
150Y 3.00mm Tin Co. Jobber Drills
£6.15
.1181 3.00mm 33 61
150Y 3.10mm Tin Co. Jobber Drills
£6.34
.1220 3.10mm 36 65
150Y 1/8 Tin Co. Jobber Drills
£6.34
.1250 1/8 1,7/16 2,9/16
150Y 3.20mm Tin Co. Jobber Drills
£6.34
.1260 3.20mm 36 65
150Y 3.30mm Tin Co. Jobber Drills
£6.34
.1299 3.30mm 36 65
150Y 3.40mm Tin Co. Jobber Drills
£6.34
.1339 3.40mm 39 70
150Y 3.50mm Tin Co. Jobber Drills
£6.53
.1378 3.50mm 39 70
150Y 3.60mm Tin Co. Jobber Drills
£7.12
.1417 3.60mm 39 70
150Y 3.70mm Tin Co. Jobber Drills
£7.12
.1457 3.70mm 39 70
150Y 3.80mm Tin Co. Jobber Drills
£7.30
.1496 3.80mm 43 75
150Y 3.90mm Tin Co. Jobber Drills
£7.30
.1535 3.90mm 43 75
150Y 4.00mm Tin Co. Jobber Drills
£7.30
.1575 4.00mm 43 75
150Y 4.10mm Tin Co. Jobber Drills
£7.50
.1614 4.10mm 43 75
150Y 4.20mm Tin Co. Jobber Drills
£7.69
.1654 4.20mm 43 75
150Y 4.40mm Tin Co. Jobber Drills
£8.84
.1732 4.40mm 47 80
150Y 4.50mm Tin Co. Jobber Drills
£8.26
.1772 4.50mm 47 80
150Y 4.60mm Tin Co. Jobber Drills
£9.22
.1811 4.60mm 47 80
150Y 4.70mm Tin Co. Jobber Drills
£9.22
.1850 4.70mm 47 80
150Y 4.80mm Tin Co. Jobber Drills
£9.42
.1890 4.80mm 52 86
150Y 4.90mm Tin Co. Jobber Drills
£9.22
.1929 4.90mm 52 86
150Y 5.00mm Tin Co. Jobber Drills
£9.42
.1968 5.00mm 52 86
150Y 5.10mm Tin Co. Jobber Drills
£10.57
.2008 5.10mm 52 86
150Y 5.30mm Tin Co. Jobber Drills
£13.44
.2087 5.30mm 52 86
150Y 5.40mm Tin Co. Jobber Drills
£13.44
.2126 5.40mm 57 93
150Y 5.50mm Tin Co. Jobber Drills
£10.76
.2165 5.50mm 57 93
150Y 5.80mm Tin Co. Jobber Drills
£17.09
.2283 5.80mm 57 93
150Y 6.00mm Tin Co. Jobber Drills
£12.11
.2362 6.00mm 57 93
150Y 6.10mm Tin Co. Jobber Drills
£14.60
.2402 6.10mm 63 101
150Y 6.30mm Tin Co. Jobber Drills
£17.09
.2480 6.30mm 63 101
150Y 6.50mm Tin Co. Jobber Drills
£13.44
.2559 6.50mm 63 101
150Y 6.80mm Tin Co. Jobber Drills
£21.13
.2677 6.80mm 69 109
150Y 7.00mm Tin Co. Jobber Drills
£14.60
.2756 7.00mm 69 109
150Y 7.20mm Tin Co. Jobber Drills
£38.82
.2835 7.20mm 69 109
150Y 7.50mm Tin Co. Jobber Drills
£15.75
.2953 7.50mm 69 109
150Y 8.00mm Tin Co. Jobber Drills
£17.29
.3150 8.00mm 75 117
150Y 8.50mm Tin Co. Jobber Drill
£18.46
.3346 8.50mm 75 117
150Y 9.00mm Tin Co. Jobber Drill
£19.98
.3543 9.00mm 81 125
150Y 9.50mm Tin Co. Jobber Drill
£21.70
.3740 9.50mm 81 125
150Y 10.00mm Tin Co. Jobber Drills
£23.44
.3937 10.00mm 87 133
150Y 11.00mm Tin Co. Jobber Drills
£30.73
.4331 11.00mm 94 142
150Y 11.50mm Tin Co. Jobber Drills
£53.80
.4528 11.50mm 94 142
150Y 12.00mm Tin Co. Jobber Drills
£37.07
.4724 12.00mm 101 151
150Y 12.50mm Tin Co. Jobber Drills
£59.54
.4921 12.50mm 101 151
150Y 13.00mm Tin Co. Jobber Drill
£43.22
.5118 13.00mm 101 151
**Inch sizes are subject to quotation and may be subject to a minimum order quantity.

Wire Gauge (Number and Letter size) are not currently being stocked with +TiN coating, but can be supplied to special order. Longer delivery

and minimum batch quantity may be sometimes expected.
