504A Side and Face Cutter - Staggered

In stock
SKU
504A
M2 High Speed Steel                           Staggered Teeth (alternate left– and right)                        BSS 122 part 1 (1953) (Fractional)
Bores with standard keyway (BSS122 or DIN138) DIN885A Type N (Metric)

Cutters for general-purpose metal removal in most materials. Cutting teeth on both sides and on face. Suitable

for continuous slotting and rebating operations at faster rates than are possible with shank-type tools. The
staggered teeth may have advantage in faster deep slotting, smoother operation and in power requirement.

*The number of teeth shown for the fractional (inch) sizes is that normally followed in UK, although BS122 itself does

not specify the number of teeth. We reserve the right to provide cutters with slightly different numbers of teeth to those
shown where stock is already available. In case a variation in the number of teeth is not acceptable, customers are asked
to make that very clear at the enquiry stage. In case cutters are to be made to special order, other tooth numbers may be
Specified: the quantity ordered will determine the unit price.
Grouped product items
Product Name Diameter Width Bore Size Keyway Number Teeth Qty
504A 3 x 7/16 x 1 Stag Side + Face
£114.46
-
3 in stock
3 7/16 1 1/4 14
504A 3 x 5/8 x 1 Stag Side + Face
£173.90
-
1 in stock
3 5/8 1 1/4 14
504A 3 x 3/4 x 1 Stag Side + Face
£187.10
-
2 in stock
3 3/4 1 1/4 14
504A 3.1/2 x 1/2 x 1.1/4 Stag Side + Face
£149.69
-
1 in stock
3,1/2 1/2 1,1/4 5/16 16
504A 4 x 1/4 x 1 Stag Side + Face
£134.28
-
20 in stock
4 1/4 1 1/4 18
504A 4 x 6.70mm x 1 Stag Side + Face
£132.09
-
14 in stock
4 6.70 1 - 18
504A 4 x 5/16 x 1 Stag Side + Face
£143.09
-
Out of stock
4 5/16 1 1/4 18
Out of stock
504A 4 x 3/8 x 1 Stag Side + Face
£149.69
-
2 in stock
4 3/8 1 1/4 16
504A 4 x 7/16 x 1 Stag Side + Face
£154.08
-
3 in stock
4 7/16 1 1/4 16
504A 4 x 1/2 x 1 Stag Side + Face
£160.69
-
1 in stock
4 1/2 1 1/4 16
504A 4 x 5/8 x 1 Stag Side + Face
£171.70
-
3 in stock
4 5/8 1 1/4 16
504A 4 x 3/4 x 1 Stag Side + Face
£187.10
-
2 in stock
4 3/4 1 1/4 16
504A 4 x 3/4 x 1.1/4 Stag Side + Face
£187.10
-
2 in stock
4 3/4 1,1/4 5/16 16
504A 5 x 5/16 x 1.1/4 Stag Side + Face
£184.91
-
4 in stock
5 5/16 1,1/4 5/16 20
504A 5 x 3/8 x 1.1/4 Stag Side + Face
£191.52
-
1 in stock
5 3/8 1,1/4 5/16 18
504A 5 x 7/16 x 1 Stag Side + Face
£200.30
-
2 in stock
5 7/16 1 1/4 18
504A 5 x 1/2 x 1 Stag Side + Face
£206.91
-
8 in stock
5 1/2 1 1/4 18
504A 5 x 1/2 x 1.1/4 Stag Side + Face
£206.91
-
5 in stock
5 1/2 1,1/4 5/16 18
504A 5 x 3/4 x 1 Stag Side + Face
£250.95
-
2 in stock
5 3/4 1 1/4 18
504A 6 x 3/16 x 1.1/4 Stag Side + Face
£244.34
-
1 in stock
6 3/16 1,1/4 5/16 24
504A 6 x 1/4 x 1 Stag Side + Face
£244.34
-
2 in stock
6 1/4 1 1/4 24
504A 6 x 1/4 x 1.1/4 Stag Side + Face
£244.34
-
2 in stock
6 1/4 1,1/4 5/16 22
504A 6 x 5/16 x 1.1/4 Stag Side + Face
£255.34
-
11 in stock
6 5/16 1,1/4 5/16 22
504A 6 x 7/16 x 1.1/4 Stag Side + Face
£272.95
-
1 in stock
6 7/16 1,1/4 5/16 20
504A 6 x 5/8 x 1.1/4 Stag Side + Face
£321.39
-
1 in stock
6 5/8 1,1/4 5/16 20
504A 6 x 3/4 x 1 Stag Side + Face
£354.41
-
1 in stock
6 3/4 1 1/4 20
504A 6 x 3/4 x 1.1/4 Stag Side + Face
£354.20
-
8 in stock
6 3/4 1,1/4 5/16 20
504A 6 x 7/8 x 1.1/4 Stag Side + Face
£418.24
-
1 in stock
6 7/8 1,1/4 5/16 20
504A 6 x 1 x 1.1/4 Stag Side + Face
£449.05
-
2 in stock
6 1 1,1/4 5/16 20
504A 50 x 5 x 16 Stag Side + Face
£79.24
-
1 in stock
50 5 16 6 10
504A 63 x 5 x 22 Stag Side + Face
£79.24
-
2 in stock
63 5 22 6 12
504A 63 x 10 x 22 Stag Side + Face
£85.86
-
3 in stock
63 10 22 6 12
504A 63 x 12 x 22 Stag Side + Face
£85.86
-
12 in stock
63 12 22 6 12
504A 63 x 16 x 22 Stag Side + Face
£94.66
-
3 in stock
63 16 22 6 12
504A 63 x 20 x 22 Stag Side + Face
£103.46
-
1 in stock
63 20 22 6 12
504A 80 x 5 x 27 Stag Side + Face
£99.07
-
19 in stock
80 5 27 7 14
504A 80 x 7 x 27 Stag Side + Face
£143.09
-
1 in stock
80 7 27 7 14
504A 80 x 10 x 27 Stag Side + Face
£110.07
-
13 in stock
80 10 27 7 14
504A 80 x 12 x 27 Stag Side + Face
£112.27
-
12 in stock
80 12 27 7 14
504A 80 x 14 x 27 Stag Side + Face
£116.67
-
2 in stock
80 14 27 7 14
504A 80 x 18 x 27 Stag Side + Face
£129.87
-
1 in stock
80 18 27 7 14
504A 100 x 4 x 1 Stag Side + Face
£132.09
-
3 in stock
100 4 1 1/4 16
504A 100 x 5 x 27 Stag Side + Face
£132.09
-
12 in stock
100 5 27* 7 16
504A 100 x 6 x 27 Stag Side + Face
£132.09
-
12 in stock
100 6 27 7 16
504A 100 x 7 x 32 Stag Side + Face
£147.48
-
1 in stock
100 7 32 8 16
504A 100 x 8 x 27 Stag Side + Face
£138.69
-
19 in stock
100 8 27 7 16
504A 100 x 8 x 32 Stag Side + Face
£138.69
-
3 in stock
100 8 32 8 16
504A 100 x 8 x 1 Stag Side + Face
£138.69
-
1 in stock
100 8 1 1/4 16
504A 100 x 12 x 27 Stag Side + Face
£145.29
-
8 in stock
100 12 27 7 16
504A 100 x 12 x 32 Stag Side + Face
£145.29
-
6 in stock
100 12 32 8 16
504A 100 x 12 x 1 Stag Side + Face
£145.29
-
2 in stock
100 12 1 1/4 16
504A 100 x 14 x 27 Stag Side + Face
£154.08
-
1 in stock
100 14 27 7 16
504A 100 x 14 x 32 Stag Side + Face
£154.08
-
7 in stock
100 14 32 8 16
504A 100 x 16 x 32 Stag Side + Face
£162.89
-
2 in stock
100 16 32 8 16
504A 100 x 16 x 1 Stag Side + Face
£162.89
-
1 in stock
100 16 1 1/4 16
504A 100 x 18 x 27 Stag Side + Face
£169.50
-
2 in stock
100 18 27 7 16
504A 100 x 18 x 32 Stag Side + Face
£169.50
-
10 in stock
100 18 32 8 16
504A 100 x 20 x 32 Stag Side + Face
£178.31
-
1 in stock
100 20 32 8 16
504A 100 x 25 x 32 Stag Side + Face
£198.11
-
6 in stock
100 25 32 8 16
504A 125 x 6 x 32 Stag Side + Face
£200.30
-
16 in stock
125 6 32 8 14
504A 125 x 8 x 32 Stag Side + Face
£200.30
-
3 in stock
125 8 32 8 16
504A 125 x 10 x 32 Stag Side + Face
£204.72
-
1 in stock
125 10 32 8 16
504A 125 x 14 x 32 Stag Side + Face
£217.93
-
4 in stock
125 14 32 8 16
504A 125 x 16 x 32 Stag Side + Face
£233.32
-
2 in stock
125 16 32 8 16
504A 125 x 22 x 32 Stag Side + Face
£272.95
-
1 in stock
125 22 32 8 16
504A 125 x 25 x 32 Stag Side + Face
£301.58
-
3 in stock
125 25 32 8 16
504A 160 x 14 x 40 Stag Side + Face
£332.39
-
1 in stock
160 14 40 10 18
504A 160 x 22 x 40 Stag Side + Face
£517.30
-
4 in stock
160 22 40 10 18
504A 160 x 32 x 40 Stag Side + Face
£649.39
-
1 in stock
160 32 40 10 18
The following similar tools may be supplied to special order: the quantity ordered determines the unit price:

Unlisted diameters and bore sizes Cutters to customer drawings
Cutters with chamfered corners Cutters in cobalt or PM-material
Cutters with radiused corners Cutters with brazed carbide tips
High rake and special geometry cutters
Gangs of cutters for special operations, full details will be required.
